Applied Nanostructures, INC.
Doing business as Applied Nanostructures
At a glance
EmployeesNot reported
In business sinceNot reported
HeadquartersMountain View, CA
US patents7
SAM.gov UEIT8TPBYQ862F9
CAGE code47Y49
Incorporated inCA
- AFM chips
- step height standards
- silicon dioxide
- scanning probe microscopes
Named on the company’s own website, read JUL 29, 2026
CareersCareers page — seen SEP 8, 2026
Supplier designations
For Profit OrganizationManufacturer of GoodsMinority Owned BusinessSubchapter S Corporation
Self-certified by the company in its SAM.gov registration
Patents
7 US patents granted 2011–2019, none of them in the five years to SEP 2025.
Measurement 5Micro-structural and nano-technology 2
- Micro heater integrated with thermal sensing assemblyUS 10,352,781 · granted JUL 16, 2019
- Vertical embedded sensor and process of manufacturing thereofUS 9,389,244 · granted JUL 12, 2016
- Scanning probe having integrated silicon tip with cantileverUS 8,828,243 · granted SEP 9, 2014
- Scanning probe devicesUS 8,397,555 · granted MAR 19, 2013
- Method of forming semiconductor devices in wafer assemblyUS 8,003,534 · granted AUG 23, 2011
Newest 5 shown · Granted to Applied Nanostructures, INC. · PatentsView (USPTO), data through SEP 30, 2025 · CC BY 4.0
