Atomera Incorporated
At a glance
EmployeesNot reported
In business since2001
HeadquartersLos Gatos, CA
US patents105
SAM.gov UEIQLS5EYMXLCH8
CAGE code20VT0
Incorporated inDE
- material called Mears
- enhances transistors
- epitaxial deposition
- mobile phone
- semiconductor
Named on the company’s own website, read JUL 29, 2026
CareersCareers page — seen SEP 8, 2026
Supplier designations
For Profit Organization
Self-certified by the company in its SAM.gov registration
Patents
105 US patents granted 2016–2025, 62 of them in the five years to SEP 2025.
Semiconductors 57Measurement 2Computer technology 2Optics 2Micro-structural and nano-technology 1
- Radio frequency (RF) semiconductor devices including a ground plane layer having a superlatticeUS 12,417,912 · granted SEP 16, 2025
- Method for making DMOS devices including a superlattice and field plate for drift region diffusionUS 12,382,689 · granted AUG 5, 2025
- Method for making semiconductor device including a superlattice and enriched silicon 28 epitaxial layerUS 12,322,594 · granted JUN 3, 2025
- Method for making semiconductor device with selective etching of superlattice to accumulate non-semiconductor atomsUS 12,315,723 · granted MAY 27, 2025
- Method for making a radio frequency silicon-on-insulator (RFSOI) wafer including a superlatticeUS 12,315,722 · granted MAY 27, 2025
Newest 5 shown · Granted to Atomera Incorporated · PatentsView (USPTO), data through SEP 30, 2025 · CC BY 4.0
Their plant
| Facility | City | State | Employees | Status |
|---|---|---|---|---|
| Atomera Incorporated | Los Gatos | CA | — | ACTIVE |
Compiled from federal records — EPA, OSHA, SAM.gov and the U.S. Census — and from the company’s own website. Federal source data is public domain. Each plant’s page names the source of every field.
