Performance NOTE: SR 1200-Series Exacta® 2 Digital Torque Wrenches are NOT designed to be used without a Global 400 or Global 400mp. The only time this tool can be operated without a process monitor is during calibration. During calibration the 1200 Series wrench must have the radio disabled. When the tool is used with a Global 400, the keypad is locked. This is part of the error proofing approach to ensure that torque values or other parameter settings are NOT changed anywhere but at the Global process monitor or in the Global Manager software. Details for this process are found in the Global Manager software owner’s manual. Sturtevant Richmont - P/N 857317 - Issue Date 161024 - Page 6 of 14 Setting Torque Values and the “Pull To Green” Threshold. This is what is required to program a 1200 for use. Using the Global Manager software, set the Unit of Measure (UOM), Minimum (Lo) Torque Specification, Maximum (Hi) Torque Specification, Mode of Operation (Track, Residual or Peak), head length, auto-clear time, direction of torque, batch size, and “green torque”. Directions are found in the Global 400 or 400mp owners guide. Calibration Prior to calibration the radio on the wrench must be turned off. There are two ways to release the tool from the Global 400. Option 1: Using the Global 400/400mp: in the programming menu go to tools, select the tool to be tested by pressing the ‘edit’ button. The page display changes and you need to press the calibrate (cal check) button. This turns
