Product line

SECURING

Made by Pdq Industries, LLC · Lancaster, PA

Hand

non-handed

Keys

two change keys per lock

Rose

2-3/8" Round, 2-15/16" Square

Trim

stainless steel or wrought brass knobs and roses

Front

2-1/4"x1-1/8", 2-1/4"x1", stainless steel or wrought brass

Modes

Standalone, Online

Finish

630 (US32D)

Keying

MK, CMK, GMK, CK; zero bitted (KO), keyed different (KD), keyed alike (KA); can be keyed into existing masterkey systems

Keyway

SCC (Schlage C compatible)

Levers

Philadelphia,Boston,Miami,Memphis,Orlando

Origin

KR

Strike

2-1/4 x 1 in stainless steel

Trim f

forged brass levers and escutcheons

Trim j

stainless steel sectional/escutcheon

Backset

2-3/4-2-3/8 in adjustable;default 2-3/4 in

Chassis

Zinc Plated

Handing

non-handed (except Memphis lever)

Ic pins

6 or 7

Keyways

SCC (Schlage C compatible);other manufacturers available

Cylinder

6 or 7 pin mortise cylinder

Finishes

605 (US3), 606 (US4), 613E, 622 (US19), 629 (US32), 630 (US32D)

Humidity

0‑95 % (Non‑Condensing)

Listings

UL 10C listed, 3‑hour fire rated auxiliary lock for A label single doors; UL 10B listed for neutral pressure doors

Warranty

1 year limited

Batteries

4 AA Alkaline

Core pins

6 or 7

Door prep

ANSI A156.115 (161) cylindrical lock

Door prep

Standard 160 or 161

Faceplate

1-1/4 x 5-5/8 in

Front dim

2-1/4 x 1-1/8 in (default);2-1/4 x 1 in faceplate

Indicator

vacant/occupied available

Latchbolt

2-3/8” - 2-3/4” (Adjustable)

Thickness

1-3/8" to 1-3/4"

Thumbturn

ADA compliant

Encryption

AES 256

Escutcheon

3-3/4"W x 9-3/4"H wrought

Handedness

non‑handed

Rose shape

round

Strike dim

2-3/4 x 1-1/8 in

Trim shape

round and square rose

Ul listing

3 hr, single doors up to 4′ × 8′

Ul listing

3‑hr UL, UL10C 3‑hr

Application

through door thru-bolting fits 160 and 161 door prep

Case design

weakened spindle

Case finish

dichromated

Credentials

RFID, Smartphone, PIN, Mechanical Key

Front bevel

0.125 in radius_2 in

Front plate

2-1/4"x1"

Lever style

Philadelphia (SFL, LFL), Boston (SFL), Miami (SFL)

Lever style

Philadelphia (SFL and LFL), Boston (SFL), Miami (SFL)

Preset door

1-3/4"

Strike type

ASA standard, T‑Strike optional, Full Lip optional

Strike type

full lip

Federal spec

FF‑H‑10C (superseded by A156.2)

Finish codes

605_606_612_613E_619_622_625_626

Front finish

stainless steel or wrought brass, beveled 1/8" on 2"

Front radius

0.25 in

Hole centers

4" to 5-1/2"

Ic core pins

6 or 7

Lever styles

Boston, Miami, Memphis, Orlando, Philadelphia

Ul latchbolt

3 hr fire test, stainless steel

Backset range

2-3/8"-2-3/4"

Case material

Steel, Yellow Chromate Plate

Certification

ANSI/BHMA 156.2 Grade 2, UL listed, TAA compliant, ADA, ICC/ANSI 117.1

Communication

BLE 4.2, BLE 5.2

Cylinder pins

6‑pin brass insert, keyed to 5‑pin

Cylinder pins

6‑pin brass insert (keyed to 5‑pin)

Cylinder type

brass mortise

Door prep dia

2-1/8 in

Ic compatible

Best;Falcon;Arrow

Keying styles

KO,KD,KA

Keys per lock

2

Keys per lock

2

Lever designs

Philadelphia, Boston, Miami, Chicago, Houston, Memphis, Orlando, Los Angeles, Dallas, Ball Knob

Rose diameter

3.375 in

Rose material

wrought brass

Rose diameter

2.5625 in

Trim material

stainless steel or wrought brass scalp

Ul dimensions

max 48"x96" single, 96"x96" active leaf pairs

Ada compliance

yes

Ada compliance

yes

Certifications

NSI Positive Pressure Fire Test (up to 3 hrs), ADA, ICC/ANSI 117.1, UL 10C (3‑hr fire rated auxiliary lock), UL 10B (neu

Chassis finish

dichromated

Deadbolt throw

1"

Door thickness

1-3/4” to 2-1/4”

Door thickness

1-3/8-1-3/4 in (Conventional Cylinder);1-1/2-2 in (SFIC)

Finish options

605 (US3), 606 (US4), 612 (US10), 613E, 619 (US15), 622 (US19), 625 (US26), 626 (US26D), antimicrobial 626, weatherized

Finish options

605 (US3), 606 (US4), 612 (US10), 613E, 625 (US26), 626 (US26D)

Front material

stainless steel; wrought brass

Keying options

MK, CMK, GMK; KO, KD, KA; master key compatible

Keying options

MK, CMK, GMK; zero bitted (KO), keyed different (KD), keyed alike (KA); can key into existing master key systems

Lever rotation

41° (standard, 2‑3/4 in backset), 65° (double doors)

Outdoor rating

IPX5 (Optional)

Rose round dia

2.375in

Strike default

Full Lip

Warranty years

2

Ansi bhma grade

Operational Grade 1, Security Grade 1

Backset default

2.75in

Finish f series

626 (US26D)

Finish j series

605 (US3),606 (US4),612 (US10),613E,622 (US19),629 (US32),630 (US32D)

Hand reversible

yes

Ic core highsec

not available

Latch faceplate

2.75in backset 1.125in faceplate; 2.375in backset 1in filler

Latchbolt throw

0.5 in (2‑3/8 in backset), 0.5625 in (2‑3/4 in backset)

Latchbolt throw

0.5"

Levers f series

Philadelphia,Boston,Miami

Levers j series

Philadelphia,Boston,Miami,Chicago,Dallas,Houston,Los Angeles,Memphis,Orlando,Ball knob

Max temperature

-20 C

Min temperature

65 C

Rose square dia

2.5625in

Strike material

stainless steel, wrought brass

Strike includes

dust box

Strike material

stainless steel or wrought brass

Strike optional

T, ASA

Thickness range

1.375-1.75 in

Backset optional

2.375in

Chassis material

cold rolled steel

Concealed screws

yes

Deadbolt backset

adjustable 2-3/8" to 2-3/4"

Front plate size

2.25 x 1.125 in

Front dimensions

2.25x1.125 in; 2.25x1 in

Front face width

1 in

Spindle material

billet steel

Armor front bevel

1/8"

Country of origin

Assembled in USA

Country of origin

Assembled in USA

Deadbolt material

investment cast stainless steel

Dust box included

yes

Front plate bevel

0.125 in @ 2 in

Latchbolt backset

2-3/8" or 2-3/4"

Latchbolt feature

anti‑friction

Strike dimensions

2-3/4"x1"

Batteries required

4 AA Alkaline Batteries

Batteries required

4 AA Alkaline Batteries

Design load rating

±70 psf (single door 3′ × 7′)

Design load rating

70 PSF_single_door_3x7 ft

Door prep hole dia

2-1/8"

Door prep standard

ANSI A156.115 (161)

Ic core compatible

Best SFIC

Latchbolt material

investment cast stainless steel

Mechanism material

diecast, investment cast, chromated cold rolled steel, stainless steel

Performance cycles

>14 million

Performance factor

11X ANSI/BHMA

Weatherized finish

optional on 626 only

Door thickness sfic

1-1/2"-2"

Keyway alternatives

other manufacturers

Trim lever material

diecast PHL, BSN, MIA

Armor front material

stainless steel (US26, US32D) / stainless steel or brass others

Door thickness range

1.75-2.25 in

Front plate material

stainless steel, wrought brass

Front plate material

stainless steel or wrought brass

Interchangeable core

available, 6‑pin, 7‑pin, large format IC core for PHL only, compatible with Best/Falcon/Arrow

Interchangeable core

6 or 7 pin, compatible with Best, Falcon & Arrow, large format IC cores compatible with Schlage

Antimicrobial coating

available

Armor front thickness

2"

Florida hvhz approval

yes

Florida hvhz approval

yes

Operating temperature

‑20 °C to 65 °C

Operating temperature

-20C to 65C

Deadbolt bolt material

brass with 1/4" case‑hardened steel roll pin

Door thickness special

2-3"

High security cylinder

available

High security cylinders

available

Keying master compatible

yes

Conventional key cylinder

6-pin keyed to 5-pin

Education code compliance

California XGT135, XGT135LED, XGT145

Icc/ansi 117.1 compliance

yes

Interchangeable core pins

6 or 7

Credential compatibilities

Prox (Optional), MIFARE DESFire EV1/EV2/EV3/Light, MIFARE Ultralight EV1/AES, MIFARE Classic

Credential compatibilities

Prox (Optional), MIFARE DESFire EV1/EV2/EV3/Light, MIFARE Ultralight EV1/AES, MIFARE Classic

Door thickness conventional

1-3/8"-1-3/4"

Interchangeable core compatible

Best, Falcon, Arrow

Interchangeable core large format

Schlage compatible

Product class

Fabricated metal safes, vaults, deposit boxes and all other fabricated metal bank and security vaults and equipmentNAPCS 2019160000
